Drill Mast LDA 92 / P

LDA92P - Excavator Mounted Drill Mast
  • 15 kN

    Extraction Force

  • 15 kN

    Crowd Force

  • 950-1030 KG

    Weight

  • 3500

    Stroke of Rotary

  • 10-12

    Suggested Excavator Size

  • HD1002

    Rotary Head

  • 90-120 LPM

    Oil Requirements

  • 200 Bar

    Operating Pressure

  • 5470 MM

    Total Length

  • 600 MM

    Side Shift Length

  • 30-130 MM

    Clamping Range

Lumesa

Catalog icon
Product Catalogue LDA92_Eng
download
  • Lumesa - LDA92
  • Lumesa - LDA92P

Light powerful drill rig attachment

Attachable crawler track to 12 t excavator with the latest technology, high manoeuvrability (360° turn, 90° swivel and 600 mm shift) and very high torque. The drilling attachment is simply mounted to the excavator by means of a quick hitch and without tools. The control unit and the optional power supply are located in a package on the mount. The drill mast is radio remote controlled. The most important drilling parameters can be read on a digital display on the radio control. Optionally, a walking foot can be mounted for use on a walking excavator.

A clamping and breaking device also allows for cased drilling.

Best suited for:

  • Self-drilling anchors (KSB R 32, R 38, R 51, T 76) up to max D 100 mm drill holes.
  • Blast hole rock drilling cased drilling
  • Working on the walking excavator



Heavy-duty powerful drill rig

Attachable crawler on 16 t excavator with state-of-the-art technology, high manoeuvrability, (360° rotation, 90° swivel and 600  mm displacement) very high torque and retraction forces. The drilling attachment is simply mounted to the excavator by means of a quick hitch and without tools. The control system as well as the optional power supply is located in a package on the mount. The drill mast is radio remote controlled. The most important drilling parameters can be read on a digital display. A drilling angle display as well as an anti-jamming system make the drill rig even more efficient. Optionally, a walking foot can be mounted for use on a walking excavator. A clamping and breaking device also allows for cased drilling.

Best suited for:

  • Self-drilling anchors (KSB R 32, R 38, R 51, T 76) up to max D 100 mm drill holes.
  • Blast hole rock drilling
  • Cased drilling
  • Working on the walking excavator
